Note Counting Machine

Heavy  Duty  Floor Type  Bundle  Note  Counting  Machine   with .5 HP  Indian  Pump   40 Waats  Arm & Spindel  Motpr  With Electronic Sensor

HEAVY  DUTY  INPOTED  SILANCE PIMP  BASE MACHINE   WITH ELECTRONIC SENSOR

Features of Kusters Note Sorting Machine M o d e l : CS 1000 (1+1) pocket

1. Number of pockets – 2

2. Full Fitness Sorter:

Soil, Tear, Missing corner, Tape Detection, Dog ears, Holes, Ink, Stains, Graffiti,

Decolouration etc.

3. Multi Functions:

3.1. Note Fitness Sorting

2.2 Note Authentication

2.3 Denomination Sorter

2.4. Mixed Currency Value counter

2.5. Facing/Orientation sorting

4. The note detection technology & fitness sorting is based on built in sensors like Full Length

Dual CIS, UV, IR, Multi-Channel Magnetics, Fluoresces, PPD, Tape, Multi-channel

Mechanical Thickness Sensors, Double detection.

5. Processing Speed: 800/1000/1200 notes per minute

6. The machine detects counterfeits & puts away in separate pocket as ‘suspect’ without

stopping the process of counting.

7. Machine rejects tape note in counting (authentication) & sorting modes.

8. Serial Number Capture

9. Daily Reports of the notes counted & sorted is recorded with an option to print.

10. The machine complies with the RBI guidelines for the “Note Authentication & Fitness

Sorting Parameters” & is upgradable for any changes in notes issued by RBI time to

time.

11. Note Travel path is straight with less chances of note jams.

12. Easy note jam removal

13. Customer Display

14. Easy upgrade: Upgradation is easy with USB

15. User friendly interface: 4.3-inch Touch Screen, Easy menu and settings.

16. Printer (optional)

The exclusive collection of our Heavy Duty Note Counting Machine is inclusive of Standard Desktop and Currency Counter (Desk Top). We are a renowned Manufacturer and Supplier of Heavy Duty Note Counting Machine from West Bengal, India. Both the Note Counting Machine that we deal in is designed under the strict supervision of experts so that the quality stays intact always. Our Note Counting Machine comes with silent workings having no noise at all. Our machine is obtainable at minimal prices.

Features :

• Vacuum Suction base technology with five suction spindles.

• Self Test operation before go to count mode.

• More reliability & high internal memory capacity.

• Advance electronic Microcontroller & SMD components for high speed.

• Useful for bundled note or loose note counting.

• Heavy duty & Low noise operation.

• Special dust collecting filters

Technical Specifications :

• Note Holding Capacity : 200 notes (approx.)

• Counting : 100 Notes / 04 Seconds

• Dimensions : 330x395x210 (WxDxH) in mm

• Weight : 22.05 kg, frequency : 50 Hz

• Power Consumption : Operating : 325W (Approx.)

• Standby : 07 W (Approx.)

• Noise Level : 70 dB (Approx.)

Currency Counter (Desk Top)

Features :

• Suction feed Technology.

• Accurate Counting on all kinds of notes including loose note & Packets.

• Transformer base technology.

• User Friendly design.

• External Display (Optional).

• Hi Speed Counting 100note / 05 Sec.

We are a distinguished Manufacturer and Supplier of Floor Mounted Note Counting Machine (TECHNO Currency) widely used to segregate heavy money bundles. Our teams of professional designers manufacture every device with care and precision to meet the high accurate counting speed features required by customers. We are a reputed firm that aims to offer customers an excellent quality Note Counting Machine at affordable prices. We accept all kinds of bulk orders from customers.

Bundle/Loose Note Counting Machine (Techno Currency Counter Floor Type)
Features :

• Suction feed technology
• Hi speed counting : 100note/05 Sec.
• Transformer base technology
• Accurate counting of both loose note and packets
• User-friendly design
• External display (Optional)
• Transformer base technology

We are a reliable Manufacturer and Supplier of Floor Mounted Note Counting Machine (TECHNO Standard) situated in West Bengal. We offer buyers an exclusive range of Floor Mounted Note Counting Machine (TECHNO Standard) loaded with high internal memory capacity, vacuum suction base technology and many other features. We accept all kinds of bulk, retail and wholesale orders from valued customers and assure them of timely deliveries.

Bundle/Loose Note Counting Machine (TECHNO STANDARD FLOOR TOP Type)
Features :

• Vacuum Suction base technology with five suction spindles
• Advance electronic microcontroller and SMD components for high speed
• More reliability and high internal memory capacity
• Self-test operation before go to count mode.
• Useful for bundied note or loose note counting
• Heavy duty and Low noise operation
• Special dust collecting filter

Technical Specifications :

• Note Holding Capacity : 200 notes (approx.)
• Counting Speed : 100 Notes /04 seconds
• Dimensions (WidthXDepthXHeight) in mm : 330X280X785
• Weight : 33.0 kg
• Working Voltage : AC 200 to 250 V
• Frequency : 50Hz
• Power Consumption : Operating: 325 W (Approx.)
• Standby : 07 W (Approx.)
• Noise Level : 70 dB( Approx.)

Vacuum suction base technology with five suction spindles Self test operation before go to count mode more reliability & high internal memory capacity Advance electronic micro controller & SMD COMPONENTS for high spreed useful for bundle note counting machine Noice leven 70dB(Aprox)

This is in reference regarding requirement of after sale  service  of banking automation product for your bank. In this regards we the firm name & style of business ,”techno  india  inc. has  service tax registered organization for provide after sale service . We provide service in  durgapur base with our  two fixed  line telephone number  for docket the break down call, and  concentrate  is  in the four district of west bengal birbhum, bankura, burdwan and purulia.also please note that we have served for last seven year  more than 300 branches, provide after sale service of more then 1400 note counting machine & about 300 other product  to sbi, ubi ,cbi, obc, wbsedcl etc. And other financial institutes in west bengal.(inclusive of our brand & also  other brand product like heavy duty note counting machines(floor top & desk top ) loose note counting machine, loose note authentication analyser (uv & mg base ), fake note detector machine, digital interest rate display board, management system, token counter etc.
